Iron Removal Filter Trolley
The Iron Removal Filter Trolley is a portable iron removal machine specially designed for extracting magnetic particles from fluid or semi-fluid materials.
The fundamental working principles of the iron removal filter trolley is based on the magnetic adsorption of magnetic rods, encompassing two stages: slurry magnetic separation and the cleaning of adsorbed magnetic substances. 1. Slurry Magnetic Separation, including Power Conveying: The pneumatic diaphragm pump, driven by 0.4-0.7 MPa compressed air, draws the material containing magnetic particles into the system. This avoids material alteration caused by the shear force of mechanical pumps; Gradient Filtration: The material first passes through a precision stainless steel filter, which intercepts large particles to prevent clogging on the magnetic rod surfaces, thereby enhancing subsequent magnetic adsorption efficiency; Deep Magnetic Removal: Magnetic particles are adsorbed onto the surface of the sleeve under the action of the Lorentz force; 2. Magnetic Substance Cleaning: When the adsorbed magnetic impurities on the rods reach a certain level, manual cleaning is required; Quick Maintenance: After shutdown, remove the filter element and magnetic rods. Clean them thoroughly before reinstalling and resetting.
-
High-efficiency Iron Removal & FiltrationMultiple sets of magnetic rods work collaboratively through series-parallel configurations, combined with filtration units, significantly enhancing iron removal efficiency and robustly ensuring the smooth operation of production lines. -
High-intensity Magnetic SeparationThe magnetic rods are constructed from high-performance permanent magnetic materials, delivering powerful and stable magnetic induction. With a surface magnetic strength ranging from 8,000 to 15,000 GS, they efficiently remove magnetic contaminants. -
Easy Installation & MaintenanceWith a rational and compact structural design, the equipment can be easily integrated into material conveying pipelines. Moreover, its components feature a snap-fit quick-release design, simplifying installation and maintenance. -
Energy Saving & Environmental ProtectionOnly compressed air is required to drive the pneumatic diaphragm pump, resulting in low energy consumption and compliance with environmental requirements.
-
Petrochemical IndustryUsed to process raw oil, catalysts, and reaction products to effectively remove iron impurities, prevent clogging and abrasion, ensure continuous and stable production, and reduce maintenance costs.
-
Food & Beverage ProcessingUsed in the processing of raw materials such as fruit juice, milk, and alcoholic beverages to remove iron impurities, improving product purity and quality.
-
New Energy IndustryUsed to eliminate iron impurities from raw materials during the manufacturing process of lithium batteries to enhance material purity and performance. In this way, the equipment contributes to increased energy density, extended cycle life, and improved safety of lithium batteries.
-
New Materials IndustryConsidering the particularity of the new materials industry, SOPHON provides customized material conveying solutions to handle special materials with high temperature, high viscosity, and corrosion.
-
Pharmaceutical IndustryTo meet the requirements of high cleanliness and sterility for material conveyance in the pharmaceutical industry, SOPHON adopts special materials and sealing design to effectively prevent cross-contamination and ensure the safety and effectiveness of drug production.
-
Plastic IndustrySOPHON provides precise and efficient material conveying systems in the plastic industry that can handle both raw material particles and finished plastic, ensuring the continuity of production process and product quality.
